K833Product Definition | |||||
| MTK6769VCZ | ||||
◇ Customer & Naming | Item | Remark | |||
◇ Customer name (Customer Name) | R |
| |||
◇ Customer project name (Customer Project Name) | M530 |
| |||
◇ Internal project name (Internal project name) | K833 |
| |||
| |||||
◇ Basic product information | Item | Remark | |||
◇ Platform (platform) | MT6769 8Core (full network access)2.0G | Pin to Pin MT6767,MT6768 | |||
◇ Platform (Platform set) | MT6769VCZ+MT6358W/A+MT6177M+MT6631N/A |
| |||
◇ Bands(Frequency band support) | Domestic versionGSM:B3/B5/B8 WCDMA:B1/B4/B5/B8 TD-SCDMA:B34/39 TDD-LTE:B38/B39/B40/B41(100M) FDD-LTE:B1/B3/B4/B5/B7/B8/B20/B28(a,b) |
| |||
◇ Form FactorAppearance Style) | Straight |
| |||
◇ LCD (Display) | TFT 2.8inch（480*640） |
| |||
◇ CTP | Capacitive touch screen 2.8 |
| |||
◇ System memory (System Memory) | 2GB+16GB |
| |||
◇ Battery (Battery capacity) | 3.8V ,3500mAh(Removable battery)polymer |
| |||
◇ Operating systemoperating system) | Android 12 |
| |||
◇ OS Languagelanguage) | English, Simplified Chinese, Traditional Chinese, Japanese, Russian, Portuguese, Spanish, French |
| |||
◇ Wireless transmission (Wireless transmission method) | BT/WiFi/NFC |
| |||
◇ NFC(Near Field Communication) | support |
| |||
◇ Location(position) | GPS/A-GPS/BeiDou/GLONASS/Galileo |
| |||
◇ Antenna : Internal antenna | GPS FPCantenna |
| |||
◇ T-flash (User memory mode) | T-FlashCard slot, maximum support256GBCapacity Card |
| |||
◇ SIM card（ SIMCard) | Single Card ( MicroSIM） |
| |||
◇ Camera (Camera) | Big Camera:400W GC4653, small camera: 200WFixed focus |
| |||
◇ USBtype) | Type-C |
| |||
◇ Quick Charging | 5V/2A |
| |||
◇ USB:OTG | supportOTGFunction |
| |||
◇bottom13PIN | Support charging andOTGFunction |
| |||
◇ Battery charging terminal (For Cradle)Charging station | Support charging station |
| |||
◇Product Description | Item | Remark/Supplier | |||
◇ Chip Set (Chipset) | MT6769 8Core (full network access)2.0G |
| |||
◇ Baseband (Baseband) | MTK6769VCZ |
| |||
◇ CPU CLOCKClock frequency) | MT6769 8Core (full network access)2.0G |
| |||
◇ Antenna (Antenna Type) | built-in | Multiple Antennas | |||
◇ Speaker SPL (speakerSPL) | 1WSpeaker unit |
| |||
◇ Receiver(earpiece) | Not supported |
| |||
◇ Microphone (microphone) | pairmic -42dB±3 | Clear voice, high sensitivity, support recording function | |||
◇ Vibrator(shock) | support | The vibration is not too weak, there is no noise and other problems | |||
◇ SIM voltage (SIMCard voltage) | 1.8/3.0V |
| |||
◇ Memory (Memory) |
|
| |||
| * NAND Flash (NANDsize) |
|
| 16 GB |
|
◇ LCD (display) |
|
| |||
| * main LCD (Home screen) | TFT 2.8inch（480*640） |
| ||
| * Surface treatment (Protective film) | Anti-glare film |
| ||
| * main LCD Backlight (Main screen backlight) | White |
| ||
| * touch panel (touchscreen) | Capacitive touch screen2.8inch |
| ||
◇ Multimedia (multimedia) |
|
| |||
| * Camera (Camera) | Big Camera:400W GC4653, small camera: 200WFixed focus |
| ||
| * Stereo sound (Stereo decoding) | support |
| ||
| * Record (recording) | support |
| ||
| * Handsfree (hands-free) | support |
| ||
| * MP3 decode (MP3) | support |
| ||
| * MPEG4 (MP4) | support |
| ||
◇ Wireless transmission (Wireless transmission) |
|
| |||
| * MMS (MMS) | support |
| ||
| * WIFI (WIFI) | 802.11a/b/g/n/ac (2.4GHz/5GHz) |
| ||
| * Bluetooth (Bluetooth version) | V5.0 | compatibleV3.0+HS/V4.2 LE | ||
◇ Battery (Battery )Note:User-accessible design |
|
| |||
| * Battery (Battery capacity) | 3.8V,3500mAh(Removable battery)polymer |
| ||
| * VoltageBattery voltage | 3.8V |
| ||
| *Backup battery | support |
| ||
◇ Accessory |
|
| |||
| * USB Cable (Data cable&charger) | Standard line,Type-Cinterface |
| ||
| * Headphone jack | Not supported |
| ||
| *Charging cradle and interface | support |
| ||
◇ME descriptionStructural Description) | Item | Remark/Supplier | |||
◇ Size(mm)Appearance size) |
|
| |||
◇ Weight (weight) |
|
| |||
◇ Cover shell material (Surface material) | Single injection molding |
| |||
◇ Decoration partDecoration) | none |
| |||
◇ Indicator (Indicator Lights) | Three colors | The red light is on when charging, the green light is on when fully charged, the green light is on when powering on, the red light is flashing when recording, and the blue light is flashing when recording | |||
◇Infrared light | 2Cell | sameK733 | |||
◇Red and blue flashing lights | red light+Blue Light |
| |||
◇White light | 1Cell | sameK733 | |||
◇Laser Light | 1Cell | sameK733 | |||
◇Light sensor | 1(for sensing automatic switching of infrared) | sameK733 | |||
◇Function key (Function keys)（3key) | Back key,Homekey/History task key, Enter key |
| |||
◇ Sidekey (Side button) | Intercom button, important file marking button, photo button, video button, recording button, emergency alarm button, power button |
| |||
◇Socket & Connector (Interfaces and Connectors) | Item | Remark/Supplier | |||
◇ Earphone socket (Headphone jack) | Not supported |
| |||
◇Charging port | Type-Cinterface |
| |||
◇Fast charging | Not supported |
| |||
◇ T-Flash socket (T-flashCard interface) | support |
| |||
◇ Sensor (Light sensor) | support |
| |||
◇Acceleration sensor (Gsensor） | support |
| |||
◇Proximity sensor (Proximity Sensor） | no |
| |||
◇Light sensor (Light Sensor） | no |
| |||
◇Electronic compass (E-Compass） | no |
| |||
◇Gyroscope (Gyroscope） | no |
| |||
◇ Geomagnetic sensor (E-Compass） | support |
| |||
◇Hall switch (Hall） | no |
| |||
◇Infrared light (IR) | support |
| |||
◇Fingerprint recognition (Finger Print） | no |
| |||
◇Others (Other） | no |
| |||
◇SW Description (Software Description) | Item | Remark/Supplier | |||
◇operating system | Android12 |
| |||
|
|
|
|
|
|
◇ | GPS |
|
| ||
|
|
| GPS antenna | Built-in, FPC | GPS/BeiDou/AGPS/GLONASS/Galileo |
|
|
|
|
|
|
◇ | NFC |
|
| ||
|
|
| NFC antenna | Built-in, FPC | Support ID card recognition |
◇ | Protection function (host) |
|
| ||
|
|
| IP67 | Dust and water resistant | according toIP67Standard design |
|
|
| Fall protection | 2 meters six sides | 2Continuous free fall from a height of meters12Times (six sides2After the wheel) the equipment is not damaged |
◇ | Environmental Conditions | environment |
| ||
|
|
| Operating Temperature ( -20℃ ~ 60℃) | Operating temperature | -20℃ ~ 60℃ |
|
|
| Storage Temperature (-30℃ ~ 70℃) | Storage temperature | -30℃ ~ 70℃ |
|
|
| Humidity (20 ~ 90%) | humidity | 20 ~ 90% |
|
|
| ESD (Contact: ±8KV / Air: ±12KV) | Static electricity | touch : ±8KVAir: ±12KV |
|
|
| RoHS 6 Compliant | RoHS | RoHS |
◇ | Certification and safety specifications | Certification |
| ||
|
|
| Europe | Europe | CE |
|
|
| Korea | South Korea | KC |
|
|
| Japan | Japan | TELEC, JATE |
|
|
| Tai Wan | Taiwan Certification | BSMI,NCC |
